TECHNICAL DATA | |
TANK CAPACITY | 600 LTR |
SUCTION CAPACITY | 71 LPM/MAX 50 BAR |
PUMP TYPE | DIAPHRAGM - MADE IN ITALY - APS 71 COMET ITALY |
TRACTOR | 24 HP AND ABOVE |
FAN | 600 MM DOUBLE FAN ( 24") - DAL DEGAN - ITALY |
NOZZLE HOLDER | M82/65 ADJUSTABLE NOZZLES |
NO. OF NOZZLES | ROUND DOUBLE FAN-10 |
SPRAY TIPS | BLANK CORE/ HOLLOW CONE ALBUZ ATR CERAMIC NOZZLES |
CHASIS | ITALIAN CHASSIS |
GEAR BOX | 2 SPEED + 1 NEUTRAL |
CONTROL UNIT | ORION OT CERAMIC BRASS CONTROLLER - COMET ITALY |
FILTERS & MIXERS | INCLUSIVE OF SUCTION FILTER 180/200 LPM AND TANK MIXERS |
PTO SHAFT | WIDE ANGLE PTO SHAFT @ 540 RPM |
OTHER | HIGH PRESSURE HYDRAULIC HOSES, AXLE, RIMS, TANK MIXERS, TUBELESS TYRES. |
WEIGHT | ROUND FAN-526 KG |
DIMENSIONS | LWH 1200 X 2440 X 1300 |
BLADE FAN INCLINATION | AIR SPEED (M/S) | AIR VOLUME (M/HOUR) | ABSORBED POWER (KW) |
35° LOW | 16.50 | 33800 | 12.5 |
35° HIGH | 30.00 | 65000 | 22.8 |
